R4T-YC 24V 4RELAY MODUAL

• Compact Design: Measuring 32.3 mm in width and 67.0 mm in length, the R4T-YC is suitable for installations where space is limited.

• High-Quality Relay: Equipped with the TAKAMISAWA NY-24W-K relay, known for its durability and suitability for inductive loads, high-frequency switching, and environments with significant electrical noise.

• User-Friendly Functions:

  • Includes LEDs for easy confirmation of contact operation status.
  • Designed for easy mounting on both rails and boards, simplifying installation processes.
  • Comes with a relay replacement tool, facilitating maintenance and reducing downtime.
  • Supplied with short bars to simplify wiring tasks.

Specifications:

• Relay Configuration: 4 points (1a x 4)
• Coil Rated Voltage: DC 24V
• Input and Output Connections: Screw-type terminal blocks
• Common Status: Independent for both input (relay coil side) and output (contact side)
• Included Accessories: Two 4P short bars
• Dimensions (W x D x H): 32.3 x 67.0 x 37.5 mm
• Mounting Method: Screw fastening or DIN rail mounting
